Velduro Phantom Frameset

Build the e-gravel bike you have always wanted.

The Velduro Phantom Frameset provides a lightweight, versatile foundation for creating a completely custom e-gravel build. Designed for everything from fast gravel riding and bikepacking to commuting and long-distance exploration, the Phantom combines responsive gravel geometry with the power of the DJI Avinox drive system.

The carbon monocoque frame and matching carbon fork have been designed to deliver a balanced combination of low weight, strength and confident handling. Clearance for tyres up to 50C gives you the freedom to tackle loose gravel, rough back roads and light trails, while multiple frame and fork mounting points make it easy to carry bottles, bags and additional equipment.

At the heart of the Phantom is the DJI Avinox M2 motor, delivering up to 110Nm of torque and 125Nm in Boost mode. Paired with the integrated 600Wh battery, it provides powerful, natural-feeling assistance for steep climbs, longer distances and fully loaded adventures.

Compatible with electronic or mechanical shifting, Shimano or SRAM drivetrains and dropper posts, the Phantom Frameset gives you the flexibility to create a bike that suits your riding style.

Key Features

• Carbon fibre monocoque e-gravel frame
• Full carbon gravel fork
• DJI Avinox M2 drive system
• Up to 110Nm of torque and 125Nm in Boost mode
• Integrated 600Wh DJI Avinox battery
• Clearance for tyres up to 50C
• Eight frame mounting points
• Six fork mounting points
• Rear rack compatibility
• Electronic and mechanical drivetrain compatibility
• Shimano and SRAM compatible
• Dropper-post compatible
• SRAM Universal Derailleur Hanger
• 12 x 142mm rear axle
• Available in Small, Medium, Large and Extra Large

Included With the Frameset

• Velduro Phantom carbon frame
• Velduro carbon gravel fork
• DJI Avinox M2 motor
• DJI Avinox 600Wh battery
• DJI Avinox display
• Left and right wireless controllers
• DJI Avinox 4A charger
• Avinox 165mm cranks
• Velduro 44T alloy chainring
• FSA headset
• FSA alloy stem
• Rear axle
• UDH derailleur hanger
• Bottle cage bolts and mounting hardware

A lightweight, adaptable platform for riders who want to build a premium e-gravel bike without compromise.

Please note: This product is a frameset and requires additional components before it can be ridden. Before using the completed bike, check the laws and regulations that apply to e-bikes in your state or territory.

Geometry
